General Specifications:
- Models: Various models within the 3650 series, including 24-port and 48-port configurations.
- Switching Capacity: Up to 440 Gbps (depending on the model).
- Forwarding Performance: Up to 130 Mpps (million packets per second) (depending on the model).
- Stacking: Supports Cisco StackWise-480 technology for stacking up to 9 switches with a total bandwidth of 480 Gbps.
- Form Factor: 1U rack-mountable.
Port Specifications:
- Port Types: 10/100/1000 Mbps (Gigabit Ethernet), 1G SFP, 10G SFP+.
- Power over Ethernet (PoE): Available on models with PoE or PoE+ capabilities, providing up to 30W per port for PoE+ and 15.4W per port for standard PoE.
Performance and Features:
- Layer 3 Routing: Supports static routing, RIP, EIGRP, OSPF, and more.
- Quality of Service (QoS): Advanced QoS features for traffic prioritization and network performance management.
- Security: Includes features like 802.1X, DHCP Snooping, Dynamic ARP Inspection, and IP Source Guard.
- Management: Supports Cisco IOS Software for management and configuration, and integration with Cisco DNA (Digital Network Architecture) for advanced network management and automation.
Software:
- Operating System: Cisco IOS XE.
- Licensing: Features vary by license level (Essentials, Advantage, or Premier).
Power:
- Power Supply: Redundant power supply options available for higher availability.
- Power Consumption: Varies by model and configuration.
Environmental and Physical:
- Temperature Range: Typically operational between 32°F to 104°F (0°C to 40°C).
- Humidity: 10% to 90% non-condensing
